Descripción
| Model | MPE-5501-ACAAB-US |
| Type | ATX 12V V2.52 |
| Dimension (W x H x D) | 140 x 150 x 86 mm |
| Input Voltage | 100-240V |
| Input Current | 8-4A |
| Input Frequency Range | 50-60Hz |
| PFC | Active PFC |
| Certifications | 80 PLUS Bronze |
| Power Good Signal | 100~500ms |
| Hold Up Time | >18ms at 100% Full Load@230Vac |
| Efficiency | 85% typical |
| MTBF | >100,000 Hours |
| Protection | OVP, OPP, SCP, UVP, OTP |
| Output Capacity | 550W |
| Max. Output Capacity | |
| Operation Temperature | 0~40°C (Nominal Input Voltage) |
| Max. Output Capacity | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| Fan | 120mm |
| Connector | MB 20+4 Pin x 1 CPU12V 4+4 Pin x 1 PCI-e 6+2 Pin x 2 SATA x 6 4Pin Peripheral x 4 |
